T4 SPOT

CT7 PROFILE
June 6, 2021
T2X BEAM
June 7, 2021
Show all

Video

Features

T4 SPOT is ready for action with an extremely flat field, a 5:1 zoom and multiple control options. Powered by a 400 W LED engine, it features one static and one rotating gobo wheel, a 7 position + white color wheel, variable frost and a 3-facet prism. T4 SPOT is a basic fixture suitable for various applications.

Technical & Specification

OPTICAL

＃Light Source: 400W white LED module
＃Color Temperature: 7,000K
＃Beam Angle: 7-35°
＃Luminaire Output: 12,000lm
＃Illuminance (7°): 38,400lux@ 5m
＃Illuminance (35°): 2,520lux@5m
＃PWM Options: 600Hz, 1200Hz, 2000Hz, 4000Hz, 6000Hz, 15000Hz
DYNAMIC EFFECT

＃Selectable Pan Ranges: 180°, 360°, 540°
＃Selectable Tilt Ranges: 90°, 180°, 270°
＃Colors: 7+white, split colors, rainbow effects at variable speeds.
＃Gobos 1: 7 rotating metal gobos+open, interchangeable gobos, indexing, rainbow effects at variable speeds
＃Gobos 2: 8 static metal gobos+open，rainbow effects at variable speeds
＃Dimmer: 0-100% electronics, 4 dimming curves options.
＃Strobe: 0-20Hz, selectable multiple strobe effects with different speeds.
＃Focus: Motorized
＃Zoom: Motorized
＃Frost: Motorized
＃Iris: Motorized
＃Prism: 3-facet prism, rotating at variable speeds.
ELECTRONIC/OPERATION TEMPERATURE

＃Input Voltage: 200V-240V, 50/60Hz
＃Power: 630W
＃Temperature (Ambient): -5°to 45°
CONTROL/CONNECTION

＃Control Protocol: DMX, RDM
＃DMX Channels: 18, 23
＃3pin XLR input/output
PHYSICAL

＃Size: 394*250*633mm
＃Weight: 26KG
＃Housing Colors: Black
＃Housing Material: High-impact flame-retardant polymer
