Technical & Specification
| OPTICAL |
#Light Source: 19 pcs 20W RGBW 4 in 1 LED
#Beam Angle: 10°-51°
#Luminaire Output: 7,430lm
#Illuminance (10°): 9,350 lux @ 5m
#Illuminance (51°): 840 lux@ 5m
#PWM Options: 600Hz, 1200Hz, 2000Hz, 4000Hz, 6000Hz, 15000Hz
|
| DYNAMIC EFFECT |
#LED: section control
#Selectable Pan Ranges: 180°, 360°, 540°
#Selectable Tilt Ranges: 90°, 180°, 260°
#Dimmer: 0-100% electronics, 4 dimming curves options.
#Strobe: 0-20Hz, selectable multiple strobe effects with different speeds.
#Zoom: Motorized
#Color Mixing：RGBW mixing or CMY mixing
|
| ELECTRONIC/OPERATION TEMPERATURE |
#Input Voltage: 100V-240V, 50/60Hz
#Power and Current: 400W, 1.8A @ 230V, 50Hz
#Temperature (Ambient): -5° to 45°
|
| CONTROL/CONNECTION |
#Control Protocol: DMX, RDM
#DMX Channels: 56/54/33/22/17/15/54MS/33MS
#3 pin XLR input/output
#USB update enabled
|
| PHYSICAL |
#Size: 303*192*361mm
#Weight: 10KG
#Housing Colors: Black
#Housing Material: Aluminum alloy
#IP rated: IP65
|
| SERIES |
WASH/BAR
|
| APPLICATION |
Architectural, Professional
|
